Efficient and Stylish Heating with the Nordflam Ragusa 9.5kW Stove

Product Specifications:

• Weight: 105.5 kg
• Rated Output: 9.5 kW
• Exhaust Outlet Diameter: 150 mm
• Heating Efficiency: 79.2%
• CO Emission at 13% O2: 0.11%
• Exhaust Gas Temperature: <550 °C
• Heating Area: 95 m²
• Dimensions (H x D x W): 861 x 632 x 446 mm
• Fuel Type: Wood of deciduous trees
• Material: Steel
• Energy Efficiency Class: A
• Warranty: 2 years
• External Air Supply Standard – Air Inlet Diameter: 90 mm

Environmental Performance:

• Seasonal Energy Efficiency at 13% O2: 69.2%
• Organic Gaseous Carbon (OGC) Emission at 13% O2: <120
• Particle Matter (PM) Emission at 13% O2: <40
• Nitrogen Oxide (NOx) Emission at 13% O2: <200
• Carbon Oxide (CO) Emission at 13% O2: <1500

Key Features:

• External Air Supply Inlet (CDP):
  • Allows independent operation from indoor air, enhancing effectiveness and reducing hazardous gas emissions.
  • Suitable for buildings with mechanical ventilation.
  • Air flows into the furnace via an inlet at the back of the base, which can be installed under or at the back of the base.
• Deflector:
  • Extends the path of fumes inside the stove, increasing heat emissions and overall heat efficiency.
• Grill:
  • Prevents logs from falling out of the insert, ensuring safe operation.
  • Withholds temperatures up to 700 °C, maintaining safety and efficiency.
• Side Glass Panel:
  • Enhances the view of the fire, creating a captivating and cozy ambiance.

The Nordflam Ragusa 9.5kW Stove is a blend of efficiency, style, and advanced technology, perfect for modern homes. Weighing 105.5 kg and crafted from high-quality steel, this stove is built to last and provide consistent warmth. Its rated output of 9.5 kW and high heating efficiency of 79.2% ensure that spaces up to 95 m² are heated effectively and efficiently.

Designed to burn wood from deciduous trees, the Ragusa stove is an eco-friendly heating solution. It complies with ECODESIGN parameters, ensuring low emissions of organic gaseous carbon, particle matter, nitrogen oxide, and carbon oxide.

The innovative external air supply system (CDP) allows the stove to operate independently of indoor air, making it suitable for buildings with mechanical ventilation. This system also helps in adjusting the effectiveness of the stove and lowering hazardous gas emissions.

The deflector feature enhances the stove’s performance by extending the path of fumes, ensuring more heat is emitted into your living space. The grill prevents logs from falling out, maintaining safety and reducing soot build-up, while the side glass panel offers a clear and enchanting view of the fire.

Backed by a 2-year warranty, the Nordflam Ragusa 9.5kW Stove promises reliable performance and peace of mind. Elevate your home’s heating efficiency and aesthetic appeal with this premium, eco-friendly stove.

For more information on Nordflam Ragusa 9.5kw call 0858754191 or visit our showroom  Kildare Stoves
