Description
Technical Specification:
Average Thermal Heat Input(Min-Max):5.26–23.12kW
Performance Efficiency(Min-Max):94.98–96.71%
Nominal Overall Power Yield(Min-Max):5.08–21.96kW
Power Delivered To Water(Min-Max):4.2–17.86kW
Power Delivered To Room(Min-Max):0.88 –4.1kWApprox.
Heating Capacity –Poor Insulation:80 –350m3Approx.
Heating Capacity –Good Insulation:240 –1,050m3
Pellet Consumption(Min-Max):1.11–4.89kg/h per pellet
Tank Capacity:42kg
Approx. burn time (Min-Max):9–37hrs
Flue Outlet Diameter:80mm
Electrical Requirement (working):140W
Electrical Requirement (starting): 350W Net
Weight:207kg
Dimensions (H x W x D):1,280 x 650x 760mm
Specifications & products may change at any time & without notice
Features:
- Modern design
- High efficiency
- Easy “plug & play” installation
- Curved glass sides
- Monoblock – steel structure, hand-welded
- Removable, air tight ash box
- Neat, integrated boiler
- Integrated, energy-efficient circulating pump
- Integrated expansion vessel
- Programmable LCD control panel
- Thermostatic control
- 5-step power setting – boiler
- Separate 5-step power setting – room
- High temperature resistant, glass-ceramic window
- Remote Control
- Wi-fi enabled for optional remote access control
- Available in a selection of colors: bordeaux, cream or black, glass door
